Velocity through ports, Mass velocity through channel/ports calculations.Plate heat exchanger dimension calculations.Pressure drop Channel/Port/Total for Hot side and Cold side Calculations.Overall Coefficient (clean / dirty) calculations.Heat load required (clean or fouled) calculations.Temperature and Flow rate estimation in the event of insufficient data.You can add your fluid physical properties and load the data to your project with a click of a button and more. Create you own database of Plates and Components.
The database also included critical properties, boiling and melting points. Estimate the Physical properties of more than 1450 components the database has the ability to estimate Thermal Conductivity, Density, Heat Capacity and Viscosity.User friendly and easy to use with ability to save/load data.
Gasketed Plate Heat Exchanger Design 2.0.1 Features: The plate dimensions and materials can be entered, this includes the size of plate heat exchanger and chevron angle (25 to 65 degrees) under single pass condition. PHex is a useful and easy to use tool that demonstrates the thermal calculations of Gasketed Plate Heat Exchangers.
Gasketed Plate Heat Exchanger Design 2.0.1 Description:
